Welljets W5600 60u Nozzle 34 Dots Small Character Continuous Inkjet Coding System
Welljets W5600 Series Printer
The Industrial high reliable performance inkjet printer with advance features will help you create more values, First choice for the upgrading inkjet printer to catch the new era of intelligent coding solution with reasonable ownership under CE .
Welljets CIJ printers advantages:
1. Offer manufacturers versatile and reliable coding solutions. With their simple design and user-friendly interface, these printers are easy to operate and require minimal maintenance. They are also highly customizable, allowing manufacturers to configure them to their specific production needs.
2. Engineered to work at high speeds, which makes them an ideal choice for manufacturers who need to code large volumes of products quickly. They are also designed to print codes accurately and consistently, even in challenging production environments. This ensures that products are properly labeled and traceable, which is essential for quality control and regulatory compliance.
3. Cost-effective performance capabilities. They use less ink than many other coding solutions, which can help manufacturers lower their operational costs. They are also easy to integrate into existing production processes, which can save time and resources.
W5600 series of CIJ printers are an excellent choice for manufacturers looking for a reliable and efficient coding solution. Their high-speed performance, accuracy, customization options, and cost-effectiveness make them a valuable addition to any production line.
| Control Panel: | 10.1 Inch LVDS High Resolution TouchScreen, Simple operation experience on new friendly interface interface |
| Hardware | 4-Core Processor, Main frequency of CPU:1.4GH withStandard 1G RAM, 8G EMMC. |
| Cabinet | Stainless Steel(304), designed to IP55. |
| Software Spec. |
| Multi-language menu | Multi-languageMenu, English, Arabic, Russian, Japanese and Persian, etc. With QT system very easy to add any language. |
| Printing Contents | Dynamic printing of 140 types of Barcode, 2D code,Chinese , English,Number.Date, time, Logo, Barcode, batch number, class type, serial number, etc |
| Software Update | Simple remote update of software with latest function. |
| Print Lines | Up to 4 lines (7*5dot)Up to 5 lines (5*5dot) |
| Fonts Size | 5X5, 5X7, 7X9, 10x12, 12X16, 18X24, 24X32 |
| Printing Speed | Up to 285m/min (5*5 fontsingle line) |
| Printing Throw Distance | Maximum 30mm from printhead to surface. |
| Printing Height | 1.8mm—15mm |
| |
| Intelligent Ink Managing | Automatically measuring system for ink consumption, clear liquid level and printing parameter. |
| Viscosity control | Automatic |
| Ink bleed control: | Automatic on start up |
| Hydraulic System | Intelligent Hydraulic System guarantee well-sealed ink and makeup |
| Protocol | MODBUS Standard Industrial Protocol |
| Standard Connection. |
| Product detector | Npn/pnp 12V 100mA for photocell or proximity detector |
| Shaft encoder | Npn/pnp eccoder Shaft encoder |
| Alarm beacon connector | Alarm beacon |
| Others Port | USB, Ethernet, I/O interface etc |
| Working Environment. |
| Temperature range: | Ambient Temp:-5°C~45°C |
| Humidity: | 30~95%RH (non-condensing) |
| Electrical requirements: | Single phase, auto rang 100-250V, 47-643Hz |
